Correa Anayak

New in 2013 with HEIDENHAIN TNC 530 HSCI
Table surface: 3,200 x 1,100 mm
Travels (X/Y/Z): 3,000/1,700/1,500 mm
Automatic head 45º UAD 0.1º/0.1º 6,000 rpm
30 tool ATC
Internal Coolant 40 Bar
Longitudinal and cross chip conveyors

Manufactured in 1998 with HEIDENHAIN TNC-410 CNC
Table: 2.000 x 700 mm.
Travel (X/Y/Z): 2.000/800/800 mm.
ISO 50
Hydraulic tool clamping
Equiped with a lot of tools and accessories

2 meter – bed type milling machine in clearance sale
Manufactured in 2000 with HEIDENHAIN TNC-410
Table size: 2,000 x 700 mm.
Travels (X/Y/Z) 2,000/800/800 mm.
Taper: ISO 50
Hydraulic Tool Clamping
Lot of tools and accessories

New in 2000. CNC HEIDENHAIN TNC-426.
Table Surface: 3.000 X 1.250 mm.
Distance between Columns:1.740 mm.
Internal Coolant
ATC 30 Tools.
External Electrospindle 18.000 rpm
90º angle head MIMATIC

Manufactured in 1997 with HEIDENHAIN TNC 426M
Table: :4,000 x 1,250 mm
Travels (X/Y/Z) :3,500/2,500/1,000 mm
Distance between columns: 2,300 mm
Direct head and 45º head
Chip conveyor

New in 2010 with CNC iTNC-530 5 axis
Table: 8.500×2.500 mm.
Travels (X/Y/Z) :8.000/3.800/1.250 mm
Distance between columns: 3.100 mm
5-axis automatic head
B/C axis oscillation range: ± 190º/± 360º
30 positions ATC

Used traveling column milling machine Correa L30/28
New in :1997
CNC HEIDENHAIN TNC-426
Table Surface :4.600 x 1.000 mm
X Travel :2.800 mm
Y Travel :1.200 mm
Z Travel  :1.500 mm

5 Axis Anayak with integrated rotary table.
New in 2010. CNC: HEIDENHAIN iTNC 530
Table 1.250 x 1.250 mm
Travels  ( X/Y/Z): 3.000/1.270/1.500 mm.
ATC 40 tools
Chip conveyor
Internal coolant 20 Bar

Bridge type Correa milling machine with autoindex head
New in 2004 with CNC Heidenhain iTNC 530
Travels (X/Y/Z): 2.500/1.000/2.350 mm.
Distance between columns: 2.350 mm.
Orthogonal 2.5º/2.5º and direct exit head
Internal cooolant
ATC 60 positions

Bridge Type Milling Machine in Clearance Sale
New in 1998. CNC HEIDENHAIN TNC-426
Table Surface : 4.000 X 1250 mm
Travels (X/Y/Z):  3.500/2.000/800 mm
Distance between Columns : 2.300 mm
Universal Head 45º 3.000 rpm
Direct Exit Head  5.000 r.p.m.

Bridge type milling machine with CNC HEIDENHAIN TNC-530
New in/reconstructed in :2003 /2021
Table surface :4.000 X 1500 mm
Travels  (X/Y/Z) :4.000/2.500/800 mm
Distance between columns :2.050 mm
Automatic head 45º 2.5º and direct exit head

Liquidation sale Bridge Type Milling Machine
New in 2001  HEIDENHAIN TNC-530 i
Table Surface :5.000 X 2.000 mm
Travels  (X/Y/Z)) :5.000/3.250/1.000 mm
Distance Between Columns :2.700 mm
UAGA Automatic Head 2.5º/2.5 º
Extended head 600 mm and direct exit head

CNC Heidenhain TNC 530.
New in 2008
Table Surface: 3.100 x 1.100 mm
Travels:2.499/1.000/1.000 mm
Autoindex head 0.1º/0.1º
Longitudinal Chip Conveyor
Internal coolant

4 meter Correa double column milling machine
New in 2006. CNC HEIDENHAIN iTNC-530
Table Surface: 4.500×2.000 mm.
Travels (X/Y/Z): 4.000/3.000/1.000 mm.
Distance between columns: 2.550 mm.
Automatic Head Othogoal UAGA 2.5º/2.5º
Direct exit head

Nicolas Correa Model CF17 D in Semi-new Condition. CNC HEIDENHAIN TNC-426 Table Surface: 2000 X 700 mm. Traverses (X/Y/Z): 2.000/800/800 mm. Hydraulic Clamping Tool. Year 2003. Immediate Delivery. Can be inspected under power

Bed type milling machine with 4th axis

New in 2006. CNC Heidenhain TNC 530

Table surface: 2.800×900 mm.

Travels  (X/Y/Z): 2.500/1.000/1.000 mm.

CNC:HEIDENHAIN TNC-426PB

Table Surface: 3.500 X 1.000 mm.

Travels (X/Y/Z):3.000/1.200/1.000 mm.

Rapid Feed:12.000 mm/min

4 meter Nicolás Correa milling machine
Manufactured in 2022 with HEIDENHAIN TNC 426 D
Table surface: 4,500×1,100 mm.
Travels (X/Y/Z): 4,000/1,200/1,500 mm.
Automatic head UDG 40 2. 5º/2. 5º
Chip conveyor

Double column Correa milling machine
New in 2007. CNC HEIDENHAIN iTNC 530
Table Surface :4.000 X 1.500 mm
Travels  (X/Y/Z) :4.000/3.000/1.000 mm
Distance between columns :2.550 mm
Automatic Head UAGA 2.5/2.5 and Direct Exit Head
Internal coolant

New in 2.002 with CNC HEIDENHAIN TNC-530
Table surface:3.800 x 1.000 mm.
Travels (X/Y/Z): 3.500/1.000/1.000 mm.
Automatic head UAD 0.1º/ 0.1º
Internal coolant 20 bar
ATC 30 tools
Longitudinal & transversal chip conveyor

New in 2007
CNC Heidenhain iTNC
Table  (C Axis) 1.250 x 1.400 mm giro 0.001º
Travels (X/Y/Z): 2.000/1.000/1.100 mm.
Autoindex Head 2. 5º/2. 5º
ATC 60 Tools
Chip Conveyor. Internal Coolant

8 meter bridge type milling machine
New in Year /Reconstruction year :1999 / 2020
CNC HEIDENHAIN TNC-530
Table Surface :8.000 X 2.000 mm
Travels  (X/Y/Z): 8.000/3.250/1.000 mm
Distance between columns:2.730 mm.
Cabezal Giro Automático con 4º y  5º Eje

Used 5 Axis Correa milling machine
New in: 1997
CNC : SIEMENS 840D /HEIDENHAIN TNC 530
Table Surface :5.000 x 2.000 mm
Travels ( X/Y/Z): 5.000 / 3.250 / 1.050 mm.
Distance between columns :2.505 mm
Automatic Head 0,001º/0,001º (5 Axis Continuous)

Second Hand Correa Diana 20 milling machine
New in  2008. CNC Heidenhain  TNC 530
Table Surface: 2.300 x 900 mm.
Travels  (X/Y/Z): 2.000/1.000/1.000 mm.
Universal Head  ISO 50

Second Hand Bed Type Milling Machine
CNC Heidenhain TNC 426 PB
New in 1998. Reconstructed in  2020
Table Surface :3.500 x 1.000 mm.
Travels ( X/Y/Z) :3.000/1.200/1.000 mm.
ATC 30 Tools
Internal Coolant

Used Correa Bedtype Milling Machine
CNC Heidenhain
Autoidex Head 2.5º/2.5º
Hydraulic Tool Clamping
Immediately Available

New in 1999. CNC Heidenhain TNC-426
ATC 30 Positions
Internal Coolant
Table Surface: 2.500×700 mm.
Travels (X/Y/Z): 2.500/800/800 mm.
Hydraulic Tool Clamping
CE Protecting Guards

Second Hand Bed Type Milling Machine
New in :2001
CNC :HEIDEHAIN TNC 426M
Table Surface :2.000 X 700 mm.
Travels (X/Y/Z) :2.000/800/800 mm.
Hydraulic Tool Clamping

Reconstructed Portal Type Milling Machine
CNC: Heidenhain TNC 530
Table Surface: 6.000 X 2.000 mm
Travels (X/Y/Z): 6.000 /3.000/ 1.000 mm
Distance between centers 2.520 mm
Direct Output Head  and 45º Head
ATC 60 Tools.

Second Hand Correa Milling Machine new in  1999
Totally Overhauled
CNC : HEIDENHAIN TNC-430
Auto Indexing Head : 2,5° / 2,5°
Table Surface : 2500 X 700 mm.

Second Hand Correa Milling Machine with CNC Siemens. New in 2001. Travels(X/Y/Z): 4000/2500/1000 mm. Distance between columns: 2000 mm. Double Chip Conveyor. Internal Coolant. ATC 30 Tools. Excellent Condition.

Second Hand Correa FP40/30 with CNC Heidenhain TNC 426 PB
New in: 2000
Travels (X/Y/Z): 3.500/2.000/800 mm.
Distance between columns: 1.740 mm.
ATC 24 Tools
Internal Coolant
Chip Conveyor

Table Surface: 2500 X 700 mm. Travels (X/Y/Z): 2500/800/800 mm. ISO 50. Hydraulic Tool Clamping. CE Guarding.

Used Correa Bed Type miling machine with Heidenhain TNC 426. Totally Overhauled. Excellent Conditions. Table Surface: 2000×700 mm. Travels (X/Y/Z): 2000/800/800 mm. Hydraulic Tool Clamping.

Used Correa L30/104. Year 2000. CNC Heidenhain TNC 426. Travels (X/Y/Z): 10.450/1.500/2.000 mm. Table Surface: 12.240×1.000 mm. AutoIndex Head 2.5º/2.5º. Chip Conveyor

Bed Type Milling Machine with Autoindex Head  2.5/2.5
Machine Model: Correa A25/30.
YOM 1992. CNC Heidenhain TNC 415.
Rotary Table Ø 400 mm
Hydraulic Tool Clamping

Used Nicolás Correa Gantry FP40/40 with 4 Axis Nikken.
Year 1997. Heidenhain TNC 426PA.
X Axis: 4 metres.
Distance between columns: 2.300 mm.
ATC 60 TOOLS.
Portable Handwheel: Heidenhain HR410.
Tool Setting Probe

Table Surface: 12.240 X 1.000 mm. Travels (X/Y/Z) : 10.450 /1.200/ 2.000 mm. Automatic Head: 2,5º – 2,5º. CNC HEIDENHAIN TNC 426. Longitudinal Chip Conveyor,.30 Tool ATC.

Second-hand Nicolás Correa fixed bench
New in 1993 with HEIDENHAIN TNC-415
Table surface: 2000 X 630 mm.
Travels (X/Y/Z) : 1800/80/800 mm.

Year 2006. CNC:HEIDENHAIN TNC-530. Rigid Tapping. 30 Positions ATC. Tool Charger H/V. Auto Indexing Head 2,5º-2,5º. Ready for 4th Axis. 4th Axis Rotary Table Spirsin Ø 600 mm. (H/V). Internal Coolant 20 Bar. Longitudinal Chip Conveyor. Portable Handwheel: HEIDENHAIN HR-410

HEIDENHAIN TNC-426 D,. New in 1998.Table Surface: 3.000 X 1.100 mm, Travels(X/Y/Z): 3.000 /1200/1000 mm,Taper: ISO 50, Turning Speeds: 20 – 3000 rpm, Head Power: 29,6 Kw, Auto Indexing Head: 2,5 º / 2,5º, Carrying Load Table: 8.000 kg, Hydraulic Tool Clamping

CNC HEIDENHAIN TNC-530.
Table Surface: 3.000 X 1.250 mm.
Distance between Columns:1.740 mm.
Travels (X/Y/Z):2.500/2.000/1.000 mm.
Distance between Shoulders:800 mm.

CNC HEIDENHAIN TNC-426. Year:1998

Table Surface: 5.000 X 1.100 mm.
Travels (X/Y/Z):5.000/ 1.200/1.500 mm.
Automatic Head:2,5 º / 2,5º.
Hydraulic Tool Clamping system.
CNC HEIDENHAIN TNC-426 D. Year:1998

CNC FAGOR 8055 MC. Table Surface: 4.590 X 1.000 mm. Travels(X/YZ):2.800/1200/1500. Rapid Traverse: 12.000 mm/min. Auto Indexing Head and Drect Exit Head. Portable Hand wheel. Year 1994
