ZAYER KPCU8000 AR
Other available Bridge and Gantry milling machines
Nicolás Correa FP 50/80 5 axis
New in 2010 with CNC iTNC-530 5 axis Table: 8.500×2.500 mm. Travels (X/Y/Z) :8.000/3.800/1.250 mm Distance between columns: 3.100 mm 5-axis automatic head B/C axis oscillation range: ±
Zayer TEBAS 5000
New in 2013 with HEIDENHAIN iTNC-530 HSCI CNC. Automatic head 45º 0.001º/0.001º 6000 rpm 43 kW Direct output head reduction 1:2.29 Automatic head changer ATC 20 tools Chip conveyor-
Used Correa FP40/30 Bridge Type Milling Machine
Used Correa FP40/30 ATC UDG Bridge Type milling machine. CNC Heidenhain TNC 426. Orthogonal Autoindex Head 2.5º/2.5º. Internal Coolant. ATC 10 Tools.
Correa RAPID-50
New in 2005 with CNC FIDIA C20 (Heidenhain TNC 530 optional) Table surface: 5,000 x 2,000 mm Travels (X/Y/Z): 5,000/3,100/1,200 mm Distance between columns: 2,800 mm. Automatic head UAD II
Technical Features of this Brige Type Milling Machine
| Year | 2006 |
| CNC | HEIDENHAIN TNC-530 |
| Table Surface | 8.000 X 2.000 mm |
| Longitudinal Traverse (X Axis) | 8.000 mm |
| Transversal Traverse (Y Axis) | 3.550 + 873 mm |
| Vertical Traverse (Z Axis) | 1.100 mm |
| Distance Between Columns | 2.800 mm |
| Rapid Traverse Axis (X ,Y ,Z) | 25.000 mm/min |
| Maximum Working Feed | 15.000 mm/min |
| Taper | MAS 403 BT 50 |
| Speed of Direct Output Head | 6.000 r.p.m. |
| Speed of Twist Head | 6.000 r.p.m. |
| Main Motor Power | 37 Kw. |
| Speed Ranges | 2 |
| Direct Output Head | INCLUDED |
| Spherical Auto Indexing Head | INCLUDED |
| Rotation A Axes | 360.000 pos |
| Rotation B Axes | 360.000 pos |
| Manual Head Changer | INCLUDED |
| Head and Gearbox Coolant | INCLUDED |
| Automatic Tool Changer | INCLUDED |
| Tools in ATC | 60 |
| Soluble Oil Lubricant Tank with Filter Paper + Magnetic Separator | INCLUDED |
| External Coolant 5 Bar | INCLUDED |
| Internal Coolant 20 Bar | INCLUDED |
| Regulable Coolant Pressure with M Functions | INCLUDED |
| Manual Head Magazine | INCLUIDO/ INCLUDED |
| Double chip conveyor at both sides of the table | INCLUDED |
| Piece Touch Probe M&H | INCLUDED |
| Guarding Doors + handrail | INCLUDED |
| Positioning Accuracy | 0.010 mm. |
| Repetitive Accuracy | 0.005 mm. |
| Machine Colour | RAL 7038 / RAL 5012 |
| Portable Handwheel | HEIDENHAIN HR-410 |
| Ethernet Connection | INCLUDED |
| Carrying Load Table | 20.000 Kg. |
| Machine Weight | 65.000 Kg. |
Detailed information of this Brige Type Milling Machine
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
