Used Soraluce FL-6000 Milling Machine
Other available Travelling column milling machines
ZAYER 30 KMU-5000
New in 1999 CNC HEIDENHAIN TNC-430PA Table Surface: :4.700 x 1.200 mm. Travel (X/Y/Z) :3.400/1.250/2.000 mm. Quill Travel (W Axis) :500 mm. Automatic Head 45º 0.001º/0.001º Twist
ZAYER 30 KCU-22000 Floor Type MiIling Machine
22 meter travelling column milling machine New inl 2000. CNC SIEMENS 840D Travels (X/Y/Z):22.000/1.500/3.000 mm. AutoIndex Head 45º 0.001º/0.001º ATC 30 Tools Internal Coolant Chip
Technical Features of this Moving Column Milling Machine
| New in | 2007 |
| CNC | Heidenhain TNC-530 |
| Table Surface | 7.000 X 2.000 mm |
| Longitudinal Traverse ( X Axis) | 5.500 mm |
| Cross Traverse (Y Axis) | 1.000 mm |
| Vertical Traverse (Z Axis) | 1.400 mm |
| Rapid Traverse | 25.000 mm/min |
| Max Working Feed | 10.000 mm/min |
| Taper | ISO-50 |
| Turning Speeds | 20 – 4.000 r.p.m. |
| Automatic Tilting Head | 2,5º -2,5º |
| ATC 30 Tools H-V | INCLUDED |
| Air Blowing Through Tooling | INCLUDED |
| Longitudinal Chip Conveyor | INCLUDED |
| Transversal Chip Conveyor | INCLUDED |
| HEIDENHAIN TS640 Piece Touch Probe | INCLUDED |
| Electrical Cabinet Cooling | INCLUDED |
| Main Motor Power | 30 Kw. |
| Speeds Ranges | 2 Ranges |
| Carrying Load Table | 2.500 Kg/m2 |
| Machine Weight | 34 Tn. |
| Machine Dimension (length x width x height) | 10.640×5.500×3.400 mm |
| Portable Handwheel | HEIDENHAIN HR-410 |
Detailed information of this Moving Column Milling Machine
Used Soraluce FL-6000 Milling Machine at our warehouse in Zaragoza ( Spain) . New in 2007 with CNC Heidenhain TNC 530. Includes autoindex head, internal coolant, 30 position automatic tool charger, and double chip conveyor. If you want to receive more information of this Used Soraluce FL-6000 Milling Machine contact us calling to our customer service number +34 976500624, to sales@maquinariacolas.com or fill the contact form at the end of the page and we will come back to you asap.
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
