Technical Features of this Second Hand VMC
| Year | 2013 |
| CNC | MAZATROL MATRIX NEXUS 2 |
| Table Surface | 3.500 x 820 mm |
| Max Weight Allowed on Table | 2.500 kg. |
| Min-Max distance from the spindle nose to the top of the table | 140-860 mm. |
| Longitudinal Travel (X- Axis) | 3.000 mm. |
| Transversal Travel (Y-Axis) | 820 mm |
| Vertical Travel (Z- Axis) | 720 mm. |
| Rapid Traverse (X, Y, Z Axis) | 50.000 mm/min |
| Max. Working Feed | |
| Includes high speed software package | |
| (Standard speed 8.000 mm/min) | 50.000 mm/min |
| Taper | CAT-40 DIN 69872 |
| Spindle Speeds | 35 to 18.000 rpm. |
| Engine Power | 35 kW |
| Automatic Tool Changer ( ATC) | INCLUDED |
| Tools at ATC | 30 |
| Synchronised Tapping | INCLUDED |
| Chip conveyor | INCLUDED |
| High pressure coolant through spindle 15 Bar | INCLUDED |
| Mazacc 3D high speed software package | INCLUDED |
| High Smoothing Control | INCLUDED |
| 3d coordinate conversion | INCLUDED |
| Maximum program size | 8 MB |
| Portable handwheel | INCLUDED |
| Machine Weight | 16.100 kg. |
Detailed information of this Second Hand VMC
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
