HERMLE C800V
Other available 5 Axis Machining Centers
DMG DMU-50 eVo linear
New in 2008 with HEIDENHAIN i-TNC 530 Rotary table 500×380 mm 0.001º ( ±360º) Travels (X/Y/Z) :500/450/400 mm Titling head :0º- 108º ATC 30 tools Internal coolant 40 bar with paper
MAZAK VTC 800/30SR
Used Mazak 5-axis center new in 2014 MAZATROL MATRIX NX2 CNC Table Surface:3,500 x 820 mm Integrated rotary table (C axis) Travels (X/Y/Z): :3,000/800/720 mm. Tilting head oscillation range
DMG DMU-160P
DMG machine center for 5-axis milling. New in 2002 with HEIDENHAIN iTNC-530 CNC Table: 1.500 x 1.250 mm. 0.001º (Continuous) Travel (X/Y/Z): 1,600/1,250/1,000 mm. Automatic head horizontal
QUASER MV 204II U/10
Used Quaser 5 axis Machining center New in 2002. CNC HEIDENHAIN ITNC530 3 pallets Turning table (C Axis): 0.001º Travels (X/Y/Z): 700/590/480 mm. Titling spindle head range (A Axis):
DMG DMU 65 monoBLOCK®
Year 2012. HEIDENHAIN TNC 530 3D Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 735/650/560 mm. Spindle speed 24,000 rpm ATC 60 tools Internal
DMG MORI DMU 75 monoBLOCK®
New in 2017. 3D CNC HEIDENHAIN TNC 640 Table surface: 800 x 650 mm. Tilting rotary table Ø650 mm 0.001º Travels (X/Y/Z): 750/650/560 mm. Spindle speed 20,000 rpm ATC 60 tools Internal
MAZAK VARIAXIS J600-5X
Second-hand Mazak 5-axis machining center Travels (X/Y/Z): 850/550/510 mm. Table tilting range (B axis): :210º (-120º +90º) 0.0001º Table rotation: 360º 0.0001º ATC 30 positions Chip
DMG DMU 125 P 5 Axis
CNC: HEIDENHAIN TNC-426.New in 2006. Table Dimension:Ø 1.250 X 1.000 mm.Travels (X/Y/Z) :1.250/880/800 mm. Table Rotation (C Axis) :0,001 º (Continuous). ATC 30 Tools. Internal Coolant . Chip
Technical Features of this 5 axis machining center
| New in | 1997 |
| CNC | HEIDENHAIN TNC-430 PA |
| Table Surface | 1.000 X 560 mm |
| X Axis Logintudinal Travel | 800 mm. |
| Y Axis Cross Travel | 600 mm |
| Z Axis Vertical Travel | 500 mm. |
| Rapid Feed (X,Y,Z) | 30.000 mm/min |
| Taper | ISO-40 |
| Spindle speed | 15.000 rpm. |
| Main spindle power | 10,5 kW |
| Total power | 21 Kwa. |
| ATC | INCLUIDO |
| ATC Positions | 2 |
| Rigid Tapping | INCLUIDO |
| Chip Conveyor | INCLUIDO |
| Portable Handwheel | HEIDENHAIN HR-410 |
| Machine Weight | 7.000 Kg. |
| Machine Dimmenssions | 2.700×2.200×2.930 |
Detailed information of this 5 axis machining center
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
