GER CM-2500 CNC
Technical Features of this Grinding Machine
| Manufacturer | GER |
| Model | CM 2500 CNC |
| Year | 2000 |
| CNC | FAGOR 8055 |
| Characteristics | |
| Distance between centre | 2.500 mm. |
| Centre height | 300 mm |
| Max grinding diameter | 595 mm. |
| Max weight between centers | 2.000 kg. |
| Max weight grinding on air | 350 kg. |
| Longitudinal movement | |
| Max programable speed | 6.000 mm/min. |
| Min programable increase | 0.001 mm |
| Cross movement | |
| Max.programable speed | 6.000 mm/min |
| Min programable increase | 0.001 mm. |
| Various | |
| Max. grinding wheel size | Ø 500/80 mm. |
| Grinding wheel Cutting Speed | 45 m/s |
| Parts Holder Centre Cone | C.M.6 |
| Centre Cone Tailstock | C.M.6 |
| 2 Steady Rests | INCLUIDO / INCLUDED |
| Machine weight | 12.000 kg. |
Detailed information of this Grinding Machine
Second-hand GER CM 2500 CNC cylindrical grinding machine for sale. Available in our Zaragoza warehouse where it can be seen in operation.
Manufactured in 2000 with FAGOR 8055, this GER cylindrical grinding machine has used two and a half meters of distance between points and 595 mm. of maximum grinding diameter
This grinding machine belongs to the CM series offering an excellent volumetric capacity for medium-sized parts that are not excessively heavy. Sectors such as printing, which produce rollers and hollow shafts with a contained mass but need excellent geometric precision and a superlative surface finish, are the natural destination for this series of machines.
The CM–CNC series, like the rest of the family of GER machines, offers a wide variety of constructive combinations and the possibility of integrating accessories that adapt each constructive unit to the specific needs of each client.
Do you want to buy a second-hand GER cylindrical grinding machine?
Then take the opportunity and contact us. You can do so by emailing sales@maquinariacolas.com, by calling +34 976500624 or by using the information and price request form. We will be happy to help you and give you all the information you need about this used GER CM 2500 CNC
ALL THE MACHINES ARE AVAILABLE SUBJECT TO PRIOR SALE
Technical specifications are not binding and may be modified without notice
